CYT1000DE single segment LED linear constant current control chip-Suzhou miaokai Electronics Co., Ltd.

CYT1000DE single segment LED linear constant current control chip

Update date：2023/10/31 Number of views：

Brand： CYT model： CYT1000DE market value： ~~0.3~~ concessional rate： 0.1

Product introduction

CYT1000DE is a single channel high voltage linear constant current LED driver, which integrates 500V high voltage MOS. The output current can be set through an external resistor between 5mA and 60mA. CYT1000DE built-in linear type thermal protection function to effectively prevent damage to the system caused by high temperature.CYT1000DE system has simple peripherals, flexible application, high reliability, small volume, low system BOM cost, adjustable packaging technology can be applied to all kinds of LED lamps.

550V/ 60mA HV NMOS integrated.

Constant current control technology.

System efficiency up to 93%.

Linear type thermal protection function.

NO EMI issue.

Various thermal protection trip temperature
